SV9100 - Access4 A to C Party CLIP transfer
SV9100 only - Access4 A to C Party CLIP transfer
CPU Firmware requirements 13.20.5f
Script Required to change the following Memory
Blocks : ( attached )
84-39-03 =1
84-39-05 =6
84-39-42 =2
Other MB’s
21-17-01 = a valid CLIP that is registered against the SIP Trunks
14-01-24 = Trunk to Trunk Outgoing Caller ID Through Mode
20-25-21 = caller ID
10-29-14 = carrier G
Other MB that may affect the feature , ensure 99-03-68 =0 ( handset programming only )
