NEC SV9100 SL2100 Manual VRS Recording via handset
Manual recording of VRS Greeting
There are 100 greetings on both the SL2100 and 200 on the SV9100
They can be used for;
MoH
Auto attendant greetings
Night announcements ( No messages to be left )
Delay announcements in ring groups ( DTMF dial out NOT supported )
From an extension with the correct Class of service ( 101 by default )
Listen to current greeting
Press speaker
Dial 616 Service code
Dial 5 Listen
Dial 001 – 100 VRS position ( 001-200 for the SV9100 )
Greeting plays if any
Press speaker
Record greeting
Lift hand piece (you can use speaker but the quality of recording is better on the handpiece)
Dial 616 Service code
Dial 7 Record
Dial 001 – 100 VRS position ( 001-200 for the SV9100 )
Start recording at the “Beep”
Press the # to end recording & replay.
