NEC SL2100 - New Install Best Practice- With Script

NEC SL2100 - New Install Best Practice- With Script


CommsPlus Distribution                IconDescription automatically generated


Best Practice for new Installs


Insert all cards that are going to be used

Firmware update CPU

Default CPU

Download Database

Run system Install script ( downloads bellow )

Make program adjustments

Ensure you perform the security requirements in SIB 329

Upload the database

Disconnect

Test the system


The script bellow will:
90-02
#   Remove un wanted logins and change the SA and UA usernames,
# IN nec-i 374772             - Unchanged
# IN tech 12345678 - Unchanged
# SA Admin 0000       - Changed
# SB             - Removed
# UA Manager 1111 - Changed

10-12 & 90-56
# set NTP and DNS
20-13
# disable call waiting messages
11-02
# remove all un used extension numbers and re-set VM to 3001-3016 ,create virtual ext 201,202
11-16
# remove single digit access codes .. Step call & Message waiting
21-05
# Set up Toll restriction classes 1-4 1=open 2= no IDD&info 3=no IDD,info&STD 4=000 only
24-02
# Set Call forward timer from default 10 seconds to 20
20-09
# set call queing for all classes  resolve VE issue
22-13
# set DDI Modes 1 , 2 and 3 table areas
10-20
# set DIM Port number
# Create Dialplan ARS to F-Route
20-08
# set Hot keypad , dial digits with out lifting handpiece
15-07 &15-20
# set line keys
15-02
# set second incoming call to one beep on handsets
26-01,26-02 & 44-05
# FRoutes and ARS added
10-02
# Location set up CLI remove 0
